Bobcat E40

E40 Compact Excavator

The Bobcat E40 compact excavator delivers one of the highest lift capacities in its size class, giving contractors a clear performance advantage on demanding construction, utility and landscaping jobs. With minimal tail swing — less than two inches of overhang — and a standard long arm for extended reach, the E40 is built to complete big projects in tight workspaces. Powered by a reliable non-DPF Bobcat engine, this compact excavator eliminates regeneration downtime while delivering strong digging and lifting performance. Carefully tuned hydraulics, a durable slew bearing and a finely matched main control valve provide smooth metering, fast cycle times and precise control when backfilling trenches or slewing a loaded bucket uphill.

Designed for durability and operator comfort, the Bobcat E40 features dual-flange track rollers for greater over-the-side lift capacity and a smoother ride across rough jobsites. The efficient cooling system with side-by-side heat exchangers improves temperature control, reduces noise and simplifies cleanout, while extended service intervals — including an increase from 500-hour to 750-hour service interval — help maximize uptime. Inside the spacious cab, tall windows, narrow pillars and a durable polycarbonate top window enhance visibility, while a suspension seat and fold-away pedals increase comfort and floor space. With options like an angle blade for faster grading, bright LED work lights and a standard lift eye for material handling, the E40 compact excavator is engineered to deliver productivity, precision and long-term reliability.

Compact Excavator Literature:

Download Compact Excavator Brochure

Download Bobcat Attachments Catalogue

Features

• Rubber Track

Options

• Cab Enclosure
• Air Conditioning
• Angle Blade

Popular Attachments

• Auger
• Clamp
• Breaker
• Hydra-Tilt
• Power-Tilt
• Plate Compactor

E40 Compact Excavator

Dimensions

• LENGTH

  192.3 in

• HEIGHT

  98.7 in

• WIDTH

  72.8 in

• WEIGHT

  9,180 lb

Engine

• ENGINE

  Tier 4

• HORSEPOWER

  40.4 hp

• FUEL TANK CAPACITY

  13.7 gal

• FUEL TYPE

  Diesel

Hydraulics

• SYSTEM RELIEF PRESSURE

  3,045 psi

• AUXILIARY STD FLOW

  16.9 gal/min

Performance

• TRAVEL SPEED - HIGH

  5.2 km/h

• TRAVEL SPEED - LOW

  2.6 km/h

• ARM DIGGING FORCE

  4,078 lbf

• BUCKET DIGGING FORCE

  7,284 lbf

• MAX DIG DEPTH

  10.9 ft

• MAX REACH AT GROUND LEVEL

  17.9 ft

• MAX DUMP HEIGHT

  12.2 ft

• RATED LIFT CAPACITY

  3,939 lb

• LIFT RADIUS

  118 in

• BOOM SWING RADIUS - LEFT

  75°

• BOOM SWING RADIUS - RIGHT

  55°

• TAIL SWING RADIUS

  Minimal
