Bobcat PA185V

PA185V

The Bobcat PA185V towable air compressor, featuring FlexAir technology, is a versatile and reliable machine that gives you a range of air power to meet your varying jobsite needs.

With the FlexAir System, you maintain complete control of both air pressure and airflow. From the control panel, you can dial in the exact combination of pressure and flow within the compressor’s operational range. The FlexAir System gives you ultimate versatility to power a variety of jobsite applications, all with a single machine.

From hand-held air tools and sandblasting to irrigation blowouts and pipeline testing, the FlexAir System allows you to adjust the pressure from 100-150 psi right at the curbside control panel (with just one button).

Bobcat Portable Air Compressor Literature:

Download Bobcat Portable Air Compressor Literature

Features

• FlexAir System: Tool-Free Adjustable Air Power

PA185V

Dimensions

• LENGTH W/ RUNNING GEAR

  137.4 in

• WIDTH W/ RUNNING GEAR

  68.5 in

• HEIGHT W/ RUNNING GEAR

  67.5 in

• TRACK W/ WITH RUNNING GEAR

  60 in

• TIRE SIZE W/ RUNNING GEAR

  15 in

• LENGTH W/O RUNNING GEAR

  88.5 in

• WIDTH W/O RUNNING GEAR

  49.3 in

• HEIGHT W/O RUNNING GEAR

  56.3 in

• SHIPPING WEIGHT W/ RUNNING GEAR

  2,269 lb

• OPERATING WEIGHT W/ RUNNING GEAR

  2,477 lb

• SHIPPING WEIGHT W/O RUNNING GEAR

  2,059 lb

• OPERATING WEIGHT W/O RUNNING GEAR

  2,267 lb

Engine

• ENGINE MAKE

  Doosan D24

• EMISSIONS TIER

  Tier 4 Final

• DISPLACEMENT

  147 in³

• SYSTEM VOLTAGE

  12 V

Capacity

• FUEL TANK CAPACITY

  34.5 gal

Operational

• RATED SPEED

  2,600 rpm

• IDLE SPEED

  1,400 rpm

Compressor

• RATED OPERATING PRESSURE

  100 psig (6.9 bar)

• PRESSURE RANGE

  80-150 psig (5.5-10.3 bar)

• FLEXAIR FLOW RANGE

  184-150 cfm (5.2-4.2 m3/min.)

• AIR DISCHARGE OUTLET SIZE

  0.75 in
